German Aircraft Instrument Panels

This book from the series "Inside" shows detailed drawings of the German aircraft instrument panels in great detail.

Instrument panels of the following aircraft:

Messerschmitt Bf 109 E-4, Messerschmitt Me 262 A, Heinkel He 111 P-1, Henschel Hs 126 B, Dornier Do 17 Z, Messerschmitt Bf 109 F-4, Fieseler Fi 156, Henschel HS 123, Focke Wulf Fw-190 A-3, Messerschmitt Bf 109 G-6, Messerschmitt Bf 109 G-12, and Junkers Ju 87 B-1.
